BINDER 680 Series 5-Pin Circular Plug, Free, M16 Locking
Industrial-grade BINDER 5-pin circular plug with M16 locking, silver-plated contacts & solder termination. Rated 250V/6A.
The BINDER 680 Series 5-Pin Circular Plug (Part No. 09 0313 00 05) is a high-performance, miniature cable connector designed for secure, reliable connections in demanding industrial environments. Featuring an M16 screw locking mechanism compliant with DIN EN 61076-2-106, this connector ensures stability under high vibration and impact loads while offering excellent EMI shielding.
Constructed with silver-plated brass (CuZn) contacts and a UL94 V-0 rated PBT contact body, this plug guarantees durability and electrical efficiency. The solder termination accommodates wire gauges of 0.75mm² (20AWG) for robust electrical performance. Its compact design simplifies installation without compromising resilience.
Key Features:
- Secure Locking: M16 screw locking prevents accidental disconnection.
- Robust Materials: Silver-plated brass contacts and flame-retardant PBT/PA housing.
- Wide Compatibility: Suitable for cables with 3mm–6mm outlet diameters.
- High Performance: Rated for 250V/6A at 40°C, operating in temperatures from -40°C to 85°C.
- Protection Rating: IP40 for basic environmental resistance.
Ideal for industrial applications requiring dependable connections in harsh conditions.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Industrial equipment wiring
- High-vibration environments
- EMI-sensitive applications
- Machinery with compact connector requirements
- Part Number: 09 0313 00 05
- No. of Contacts: 5 (Solder Pin)
- Cable Outlet Diameter: 3mm–6mm
- Termination: Solder
- Wire Gauge: 0.75mm² (20AWG)
- Rated Voltage: 250V
- Rated Current: 6A at 40°C
- Contact Material: Brass (CuZn) with Silver (Ag) Plating
- Contact Body: UL94 V-0 PBT
- Housing: UL94 HB Polyamide (PA)
- Locking: M16 Screw (DIN EN 61076-2-106)
- Protection Rating: IP40
- Temperature Range: -40°C to 85°C
- Shell Style: Cable Mount Plug
- Product Range: 680 Series
- Weight: 20g
