BLOCK AVB Series 2.3VA PCB Safety Transformer, 2 x 6V, 115V Primary

The BLOCK AVB Series 2.3VA PCB Safety Transformer is an encapsulated safety isolating transformer designed for the safe electrical isolation of input and output sides. It is ideal for creating SELV and PELV circuits due to its output voltage limitation, ensuring enhanced safety in various electrical applications.

This transformer is engineered to operate reliably in high ambient temperatures and is inherently short-circuit proof, offering robust protection. Its compact design delivers maximum output while minimizing size, making it suitable for space-constrained applications. The dual primary (2 x 115V) and dual secondary (2 x 6V) windings allow for flexible series or parallel connections, adapting to different voltage and current requirements.

Key Features

• Safety Isolating: Provides safe electrical isolation for SELV and PELV circuits.
• Dual Windings: Dual primary and dual secondary for series or parallel connection.
• Compact & High Output: Minimum size with maximum power density.
• Thermal Performance: Designed for high ambient temperatures.
• Reliability: XtraDenseFill resin encapsulation ensures permanent corrosion protection, high insulation value, and maximum electrical reliability.
• Self-Extinguishing Materials: Potting and hood materials are self-extinguishing for added safety.

With a power rating of 2.3VA, an output current of 191mA, and a frequency range of 50Hz/60Hz, this through-hole mounted transformer is a reliable choice for industrial, power management, and safety applications. Its robust construction and advanced encapsulation technology guarantee long-term performance and durability.
