CAMDENBOSS 5.08mm 5-Pole Pluggable Terminal Block, 15A, 1.5mm²
High-performance 5.08mm pluggable terminal block with 15A rating, 1.5mm² wire compatibility, and industrial-grade insulation.
The CAMDENBOSS 5.08mm 5-Pole Pluggable Terminal Block offers secure and efficient connections with 15A current rating and support for wire sizes ranging from 28AWG to 14AWG (1.5mm²). With a professional rising clamp mechanism, this terminal block ensures strong connections while preventing solder wicking for enhanced reliability. The brass, nickel-plated rising clamp and tin-plated brass pin provide excellent conductivity and durability in demanding environments.
Key Features
- Captive screws prevent loss during maintenance or installation.
- Guided pin alignment ensures easy and precise mating with compatible sockets.
- High insulation resistance (500MΩ @ 500V) and withstands AC2000V for 1 minute, ensuring safety in high-voltage applications.
- Low contact resistance (20mΩ), minimising power loss and heat generation.
- Wide working temperature range from -40°C to 105°C, making it suitable for industrial and harsh environments.
Technical Specifications
- Wire Size: 28AWG to 14AWG (1.5mm²)
- Connection Method: Rising Clamp
- Rated Current: 15A
- Rated Voltage: 300V
- Length: 25.4mm
- Pitch Spacing: 5.08mm
- No. of Positions: 5-Way
- Material: Nickel-plated brass (clamp), tin-plated brass (pin), zinc-plated steel (screws)
Ideal for electrical panels, automation systems, and industrial controls, this CamBlock Plus terminal block combines durability and performance for secure wire terminations.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
Technical Specifications
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Electrical panels & control systems
- Industrial automation wiring
- Power distribution assemblies
- Machinery & equipment wiring
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Wire Size: 28AWG to 14AWG (1.5mm²)
- Connector Type: Pluggable Terminal Block
- Insulation Resistance: 500Mohm at 500V
- Withstands AC2000V for 1 minute
- Contact Resistance: 20mΩ
- Working Temperature: -40°C to 105°C
- Clamp Material: Brass, nickel-plated
- Pin Material: Tin-plated brass
- Screw: M3 steel, zinc-plated
- Length: 25.4mm
- Pitch Spacing: 5.08mm
- Number of Positions: 5-way
- Rated Current: 15A
- Rated Voltage: 300V
- Wire Connection Method: Clamp
- Product Range: CamBlock Plus
- Weight: 10g
