CAMDENBOSS PCB Terminal Block, 5mm, 2-Way, UL94-V0 PA
Professional 2-way PCB terminal block with rising clamp for 0.2-4mm² cables. UL94-V0 flame retardant PA, approved for industrial use.
The CAMDENBOSS PCB Terminal Block is a professional-grade solution designed for secure and reliable electrical connections in PCB applications. Featuring a large cable entry rising clamp mechanism, this terminal block ensures easy insertion and firm retention of cables.
Key Features
- Material: Moulded in green UL94-V0 flame-retardant polyamide (PA) for excellent fire resistance
- Compatibility: Accepts both solid (0.2-4mm² / 30-12AWG) and stranded (0.2-2.5mm² / 30-12AWG) cables
- Enhanced Stability: Double-row pins for superior board stability
- Certified Safety: UL recognised and VDE approved for professional use
- Clamp Type: Professional rising clamp for secure wire termination
Electrical Specifications
- Current Rating: 24A/250V (AC)
- Dielectric Strength: 2kV for insulation reliability
- Operating Temperature Range: Up to 110°C
- Conductor Capacity: 4mm² maximum CSA
Mechanical Specifications
- Pitch Spacing: 5mm between terminals
- PCB Hole Size: 1.5mm for through-board mounting
- Orientation: Through-hole right-angle configuration
Ideal for industrial, commercial and DIY electronics projects requiring durable, high-performance terminal connections with excellent electrical characteristics.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- PCB mounting applications
- Industrial control systems
- Power distribution boards
- Electrical equipment wiring
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Material: UL94-V0 flame retardant PA (polyamide)
- Wire Compatibility: 2x 0.2-4mm² (30-12AWG) solid cable
- Wire Compatibility: 2x 0.2-2.5mm² (30-12AWG) stranded cable
- Pitch Spacing: 5mm
- Number of Ways: 2
- Wire Connection Method: Screw clamp
- Rated Current: 16A/24A
- Rated Voltage: 250V/300V
- Dielectric Strength: 2kV
- Operating Temperature: 110°C
- PCB Hole Size: 1.5mm
- Block Orientation: Through Hole Right Angle
- Product Range: CTB09VG
- Approvals: UL Recognised, VDE Approved
