EUROPA TR2-D Thermal Overload Relay, 9-13A

The EUROPA TR2-D Thermal Overload Relay is a crucial component designed to protect electric motors from damage caused by overloads and phase failure. It operates within a precise setting range of 9-13A, offering reliable motor protection and ensuring system longevity. This relay meets stringent international standards, including IEC 60947-1, IEC 60947-4-1, NFC 63-650, VDE 0660, and BS 4941, guaranteeing high performance and safety in industrial environments.

Built with robust protection features, it boasts an insulation voltage of 690V and an operating voltage of 600V, making it suitable for a wide range of applications. The relay includes VDE 0106 protection against finger contact, rated IP2x, enhancing operator safety during installation and maintenance. Its high dielectric strength and impulse withstand voltage ensure reliable operation under demanding electrical conditions.

A key feature is its sensitivity to phase failure, which triggers a trip when the current exceeds 25% above the rated current (In), providing essential protection against unbalanced supply conditions that can damage motors. The tripping class is 10, and it functions effectively within frequency limits of up to 400Hz.

Specifications at a Glance

• Setting Range: 9-13A
• Tripping Class: 10
• Insulation/Operating Voltage: 690V / 600V
• Frequency Limits: 400Hz
• Protection Rating: IP2x (VDE 0106)
• Phase Failure Sensitivity: Trips at 25% above In
• Comprehensive Standards Compliance: IEC, VDE, NFC, BS

Compact and reliable, the EUROPA TR2-D is an indispensable safeguard for motor control circuits, helping to prevent costly downtime and equipment damage.
