JST PUD 2mm Pin Header, Top Entry, 2 Rows, 12 Contacts, Through Hole

Top-Entry Pin Header for Compact Electronics

This JST PUD pin header provides a reliable top-entry wire-to-board connection with a 2 mm pitch and dual-row configuration. Designed for dense electronic assemblies, the 12-contact layout ensures secure multi-way connections while saving valuable board space. Its through-hole design offers strong mechanical retention and stable soldering, making it suitable for robust PCB integration in a wide range of applications.

The compact dual-row construction offers efficient routing and high connection density, ideal for modern devices where size and reliability are key. Whether used in prototyping, industrial controls, or consumer electronics, this header delivers consistent performance. The top-entry orientation simplifies wire insertion and maintenance, enabling quick and secure wiring in tight spaces.

Features

• 2 mm pitch for space-efficient designs
• Dual-row layout for high-density connections
• 12 contacts for multi-way signal or power distribution
• Through-hole termination for durable PCB mounting
• Top-entry orientation for easy wire access
• Compact dimensions: 43 mm height, 33 mm width, 15 mm depth

Specifications

• Type: Pin Header, Top Entry
• Connection: Wire-to-Board
• Pitch: 2 mm
• Number of Rows: 2
• Number of Contacts: 12
• Mounting Type: Through Hole
• Series: PUD

This pin header is an ideal choice for engineers seeking a dependable and compact interconnection solution. Its space-saving design and sturdy construction make it a versatile component for various electronic assemblies, ensuring long-term reliability and ease of use.
