MARQUARDT Illuminated Rocker Switch, Off On, DPST, 250V AC, 20A

The MARQUARDT 1930 Series Illuminated Rocker Switch provides a robust and highly functional control solution for demanding environments. This double-pole single-throw (DPST) switch is designed with an integrated ON/OFF function and is clearly illuminated for status indication, ensuring safe and intuitive operation even in low-light conditions.

Built for reliability, the switch features silver-plated contacts and external bearing connections, which offer excellent conductivity and corrosion resistance for a long electrical service life. The main housing is constructed from durable black polyamide (PA), providing a high level of mechanical strength and insulation.

Key Features & Performance

Rated for up to 20A at 250V AC, this switch is suitable for controlling a wide range of industrial equipment. It boasts a high IP65 protection rating, making it fully dust-tight and protected against low-pressure water jets from any direction. This makes it ideal for use in panels or enclosures that may be exposed to harsh conditions, including dust, dirt, and occasional washdowns.

The actuator is a transparent rocker, allowing the internal illumination to shine through clearly. Connection is simplified via a 6.3mm quick-connect terminal system, enabling fast and secure wiring without the need for soldering. The switch offers a crisp tactile feel with an operating force between 3 and 8N.

Technical Specifications

• Switch Operation: Off-On
• Contact Configuration: DPST (Double-Pole, Single-Throw)
• Illumination: Yes, illuminated actuator
• Mounting Type: Panel Mount
• Actuator Colour: Transparent
• Contact Material: Silver-plated
• Terminal Type: 6.3mm Quick-Connect
• Protection Rating: IP65 (Dust-tight and protected against water jets)
• Housing Material: Black Polyamide (PA)

With its blend
