MEAN WELL DDR-60 12V 5A 60W Isolated DIN Rail DC/DC Converter

The MEAN WELL DDR-60 Series Isolated DIN Rail DC/DC Converter is a robust, high-efficiency power solution designed for industrial control panels and demanding electrical environments. With an impressive 60W output, this unit provides a stable 12V DC supply at up to 5A, making it ideal for powering PLCs, sensors, relays, and other critical control system components.

A standout feature is its 4:1 ultra-wide input voltage range (9-36V DC), allowing it to be used with a variety of battery and supply voltages, including common 12V, 24V, and 36V systems. This flexibility is matched by an extensive operating temperature range of -40°C to +85°C, ensuring reliable performance in harsh conditions from freezing cold to intense heat. No minimum load is required, simplifying system design.

For safety and durability, the converter boasts 4kV DC reinforced isolation between input and output, providing superior protection against transients and ground loops. It is packed with comprehensive protective functions, including safeguards against short circuit, overload, overvoltage, input reverse polarity, and input undervoltage. The output voltage is adjustable by ±10% for fine-tuning to your specific application needs.

Installation is quick and secure thanks to the DIN rail mount design, compatible with standard TS-35/7.5 or TS-35/15 rails. Its ultra-slim width of just 52.5mm (3SU) saves valuable space within enclosures, while free air convection cooling eliminates the need for fans, reducing maintenance and potential points of failure.

Key Features:

• Ultra-Wide 4:1 Input Range: 9-36V DC input.
• High Isolation: 4kV DC reinforced isolation.
• Wide Temperature Range: Operates from -40°C to +85°C.
• Compact Design: Only 52.5mm wide for space-saving installation.
• Full Protection Suite: Short circuit, overload, overvoltage, reverse polarity, and
