MOLEX / BRAD Ultra-Lock Sensor Cable, M12 Socket to Free End, 300mm

The MOLEX / BRAD Ultra-Lock Sensor Cable is a high-performance connection solution featuring an M12 (Ultra-Lock) receptacle to a free end. This cable is designed for reliable data and signal transmission in demanding industrial environments, offering a secure and durable connection.

The female straight connector is crafted from nickel-plated brass, providing excellent corrosion resistance and durability. The cable uses 0.25mm² PVC leads (24AWG) and supports up to 8 positions, with a maximum current of 2.0A per contact and a maximum voltage of 30V AC / 36V DC. It operates effectively over a wide temperature range from -25°C to +90°C, ensuring dependable performance in various conditions.

With its M16 x 1.5mm mounting threads and internal thread coupling, this cable is designed for front panel mounting, offering a secure and stable installation. The IP69K and NEMA 6 rating guarantee protection against high-pressure water jets, dust, and temporary immersion, making it ideal for harsh industrial applications.

The cable length is 0.30 meters, providing flexibility for compact installations. This sensor cable is widely used in automation, control systems, and other industrial applications where reliable connectivity is essential.
