ONSEMI J175 P-Channel JFET Transistor, 30V, TO-92

The ONSEMI J175_D26Z is a P-channel junction field-effect transistor (JFET) engineered for precise, low-level signal control. Designed using process 88, it excels in applications requiring high-impedance switching and minimal signal interference, making it a reliable choice for sensitive analogue circuitry.

This JFET is characterised by a maximum gate-source breakdown voltage of 30V, ensuring robust operation within its specified range. It features a zero-gate-voltage drain current (Idss) with a minimum of -7mA and a maximum of -60mA, providing a consistent current handling capability. The gate-source cutoff voltage is specified at a maximum of 6V, allowing for effective channel control with relatively low input voltages.

Key Features & Applications

• Analogue Switching: Ideal for low-level analogue switching, sample-and-hold circuits, and chopper-stabilised amplifiers where signal integrity is paramount.
• Industrial Use: Suited for a variety of industrial control and instrumentation applications demanding stable performance.
• Through-Hole Design: The classic TO-92 case style and through-hole mounting make it easy to prototype and integrate into existing PCB designs.
• High-Temperature Tolerance: Capable of operating at temperatures up to 150°C, ensuring reliability in demanding environments.

With its three-pin configuration and P-channel operation, the J175 offers designers a straightforward and effective solution for managing signal paths in critical circuits. Its combination of electrical specifications and physical robustness makes it a staple component for electronic design engineers.
