TT Electronics 7286R5KL.25 5kΩ 10 Turn Precision Wirewound Potentiometer, 2W, B
TT Electronics 5kΩ 10-turn precision wirewound potentiometer. 2W, linear taper, IP50/IP66, turret terminals. Ideal for calibration.
Precision Control for Demanding Applications
The TT Electronics 7286R5KL.25 is a high-quality, wirewound precision potentiometer designed for applications that require accurate and stable adjustment. This 5kΩ, 10-turn potentiometer features a linear taper for precise, predictable control across its full range.
With a 2W power rating and a robust wirewound element, this potentiometer ensures reliable performance and long-term stability. The bushing mount and screwdriver slot adjustment make it easy to install and fine-tune, while the turret terminals provide secure and reliable connections.
Engineered for industrial environments, the potentiometer offers a wide operating temperature range from -55°C to 125°C and is rated IP50/IP66 for protection against dust and water jets. Its ±5% resistance tolerance and ±20ppm/°C temperature coefficient guarantee consistent operation under varying conditions.
The potentiometer also features a maximum noise of 100Ω and a dielectric strength of 1000Vrms, ensuring signal integrity and electrical safety. With 1° maximum backlash, this potentiometer delivers accurate and repeatable adjustments, making it an excellent choice for equipment requiring precise calibration.
Key Features & Specifications
- Resistance: 5kΩ
- Number of Turns: 10
- Track Taper: Linear
- Power Rating: 2W
- Resistance Tolerance: ±5%
- Technology: Wirewound
- Mounting: Bushing Mount
- Adjustment Type: Screwdriver Slot
- Terminals: Turret
- Operating Temperature: -55°C to +125°C
- Protection Rating: IP50/IP66
- Backlash: 1° Maximum
- Dielectric Strength: 1000Vrms
- Maximum Noise: 100Ω
