VISHAY 2-Channel Optocoupler, Transistor Output, DIP, 8-Pin, 5.3kV

The VISHAY 2-Channel Optocoupler with a phototransistor output is designed to provide reliable electrical isolation and signal transmission in demanding electronic applications. Featuring a dual-channel configuration, this component is ideal for circuits requiring compact, space-saving isolation solutions.

This optocoupler boasts a high collector-emitter voltage (BVCEO) of 70V, ensuring robust performance in various operating conditions. It offers an improved common-mode rejection capability, which enhances signal integrity by minimising the impact of common-mode noise. Additionally, the device provides a better channel-to-channel current transfer ratio (CTR) match, guaranteeing consistent performance across both channels.

Key Features

• High isolation test voltage of 5300 VRMS (5.3kV) for superior electrical isolation
• Phototransistor output for reliable switching
• Dual-channel design for compact integration
• Improved common mode rejection to maintain signal clarity
• Better channel-to-channel CTR match for consistent operation
• Maximum forward current of 60mA
• Minimum CTR of 100%

Encased in a standard DIP (Dual In-line Package) with 8 pins, this optocoupler is straightforward to integrate into printed circuit board designs. Its robust specifications make it a dependable choice for electronics designers seeking high-performance isolation components.
