WAGO 224-112 2 Pole Lighting Connector, 2.5mm², White
WAGO 224-112 lighting connector for solid & fine-stranded conductors (2.5mm², 24A, 400V), tool-free installation.
The WAGO 224-112 2 Pole Lighting Connector provides a reliable and tool-free connection between solid and fine-stranded conductors, making it an ideal solution for various electrical installations in buildings. This lighting connector is approved as independent equipment according to EN 60998, ensuring compliance with safety standards for household and similar applications.
Key Features:
- Quick and easy push-in connection for solid conductors on the installation side.
- Tool-free connection for fine-stranded conductors on the lighting side—simply press the block together.
- Suitable for a wide range of applications, including industrial, communications, lighting, security, signalling, and HVAC.
- High performance with a continuous service temperature of up to 105°C.
Applications:
This connector is versatile and can be used in numerous electrical scenarios where secure and efficient conductor connections are needed. Its compact and durable design ensures long-lasting performance even in demanding environments.
Technical Specifications:
- Current Rating: 24A
- Voltage Rating: 400V
- Installation Side (Solid Conductors): 1-2.5mm²
- Lighting Side (Solid & Fine-Stranded Conductors): 0.5-2.5mm²
- Dimensions: 9.5mm (W) x 15.5mm (H) x 20.5mm (D)
- Continuous Service Temperature: 105°C
- Wire Size: 16AWG (max) to 20AWG (min)
- Contact Material: Tin-plated copper
- Mounting Type: Cable mount
- Connector Type: Terminal block (standard)
- Number of Contacts: 1
With its easy installation, high current rating, and compact size, the WAGO 224-112 is the perfect choice for professionals seeking a secure and efficient electrical connection solution.
- Industrial applications
- Communications & networking
- Lighting installations
- Security systems
- Current Rating: 24A
- Voltage Rating: 400V
- Installation Side (Solid Conductors): 1-2.5mm²
- Lighting Side (Solid & Fine-Stranded Conductors): 0.5-2.5mm²
- Dimensions: 9.5mm (W) x 15.5mm (H) x 20.5mm (D)
- Continuous Service Temperature: 105°C
- Wire Size: 16AWG (max) to 20AWG (min)
- Contact Material: Tin-plated copper
- Mounting Type: Cable mount
- Connector Type: Terminal block (standard)
- Number of Contacts: 1
- Weight: 900g
