WAGO Junction Box for 222, 773 & 2276 Series, 126x115x55mm
Versatile polyethylene junction box for WAGO connectors, supporting up to 450V AC & 41A with tool-free installation.
The WAGOBOX XLA Junction Box is a versatile electrical enclosure designed specifically for use with WAGO 222 and 773 series connectors, providing a secure and efficient solution for cable connections.
With a robust polyethylene (PE) construction, this junction box is durable and resistant to various environmental factors. It has an IPX2 rating, making it suitable for protected environments where minimal water resistance is required.
Key Features
- High Voltage Capacity: Rated up to 450V AC / 41A, ensuring reliability for a wide range of applications.
- Wide Conductor Compatibility: Supports 0.08mm² to 6mm² conductors, including flexible and stranded wires.
- High Connection Capacity: Accommodates up to 36 individual conductor connections (when using twelve 3-core 1mm² cables) or 12 connections with 6mm² conductors (with six 3-core cables).
- Secure Cable Clamping: Built-in clamps securely grip 3mm to 15mm diameter cables, holding up to 12 cables without slippage.
- Tool-Free Installation: Simple snap-on assembly requires no additional tools, saving time and effort.
Compatibility
The junction box works seamlessly with multiple WAGO connector series, including:
- 222 Series Lever-Nuts
- 773 Series Push-Wire Connectors
- 2276 Series Compact Connectors
- 221 Series Splicing Connectors
Dimensions & Specifications
- External Dimensions (Metric): 126mm (Depth) × 115mm (Width) × 55mm (Height)
- External Dimensions (Imperial): 4.96
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Electrical wiring in residential and commercial buildings
- Industrial control panels
- Lighting installations
- HVAC systems
- Material: Polyethylene (PE)
- Voltage Rating: 450V AC / 41A
- Conductor Compatibility: 0.08mm² to 6mm²
- Max Conductor Connections: 36 (with 1mm² cables), 12 (with 6mm² cables)
- Cable Clamp Capacity: 12 cables (3-15mm diameter)
- IP Rating: IPX2
- Colour: Grey
- Dimensions (Metric): 126mm (D) × 115mm (W) × 55mm (H)
- Dimensions (Imperial): 4.96″ (D) × 4.527″ (W) × 2.165″ (H)
- Tool-Free Installation: Yes
Always follow local regulations and product guidance.
