Amphenol 15-Pin High-Density D-Sub Plug, Gold Plated
High-density 15-pin D-Sub plug with gold-plated contacts for industrial and telecom applications. Rated 3A/600V.
The Amphenol 15-Pin High-Density D-Sub Plug is a premium-grade connector designed to provide superior signal density and reliable performance in demanding industrial and telecom applications. Part of Amphenol's extensive D-Sub connector line, this high-density variant features decreased contact spacing, allowing for greater signal transmission efficiency compared to conventional D-Sub connectors.
Key Features
- Shell: Steel with nickel plating for durability and corrosion resistance.
- Insulator: Glass-filled thermoplastic (UL 94V-0 rated) ensuring high-temperature resistance and electrical safety.
- Contacts: Copper alloy with selective gold plating for optimal conductivity and longevity.
- Electrical Ratings: Handles up to 3A current and 600V AC/rms (50Hz), with a withstanding voltage of 1000V AC/rms (50Hz) for one minute.
- High Performance: Boasts 5000MΩ insulation resistance and a maximum contact resistance of 10mΩ.
- Wide Temperature Range: Operates reliably from -55°C to +125°C, making it suitable for extreme environments.
Applications
This high-density D-Sub plug is ideal for:
- Industrial automation systems
- Telecom and networking equipment
- Standard I/O connections
Installation & Compatibility
This DE shell-size connector is configured as a plug and features solder-type termination for secure electrical connections. Designed for through-hole mounting, it ensures stability and ease of integration into various electronic assemblies.
Whether you require robust performance in harsh conditions or efficient signal management in high-density applications, the Amphenol 15-pin HD D-Sub plug delivers unparalleled reliability and quality.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Industrial systems
- Telecom equipment
- Standard I/O connections
- High-density signal applications
- Shell: Steel with Nickel plating
- Insulator: Glass-filled thermoplastic, UL 94V-0
- Contacts: Copper alloy, selective Gold plating
- Current Rating: 3A
- Voltage Rating: 600V AC/rms 50Hz
- Withstanding Voltage: 1000V AC/rms 50Hz for one minute
- Insulation Resistance: 5000MΩ
- Contact Resistance: 10mΩ Max
- Operating Temperature Range: -55°C to +125°C
- D Sub Connector Type: High Density (HD)
- Gender: Plug
- No. of Contacts: 15
- D Sub Shell Size: DE
- Contact Termination Type: Solder
- Connector Mounting: Through Hole Mount
- Contact Material: Copper Alloy
- Contact Plating: Gold Plated
- Connector Body Material: Steel
- Weight: 10g
