NEUTRIK Ethercon RJ45 Connector Boot, 3.5-8mm Cable Diameter
Durable NEUTRIK Ethercon RJ45 connector boot for secure Ethernet connections in harsh environments.
The NEUTRIK Ethercon RJ45 Connector Boot (NE8MX-B-1) is a robust and reliable solution for protecting Ethernet connections in harsh environments. This connector carrier features a durable black chromium shell, chuck, and boot, designed to safeguard the fragile components of standard RJ45 connectors.
With a cable diameter range of 3.5-8mm, this boot is compatible with the X-series and is ideal for non pre-assembled conventional RJ45 cables. Its rugged die-cast shell and unique chuck-type strain relief ensure excellent durability and strain resistance, making it suitable for demanding commercial applications.
Key Features
- Rugged construction – Die-cast shell and high-quality materials for long-lasting performance
- Secure strain relief – Unique chuck design protects cables from damage
- Wide compatibility – Accepts the most common RJ45 plugs
- Harsh environment ready – Built to withstand tough conditions and prevent connector breakage
- Shielded – Enhances signal integrity by reducing interference
Technical Specifications
- Modular Connector Type: RJ45 Plug
- Port Configuration: 1 x 1 (Port)
- No. of Positions (per Port): 8P8C
- Connector Mounting: Cable Mount
- Connector Orientation: Straight
- Shielding: Shielded
- Magnetics: No
- LEDs: No
- Light Pipes: No
- Product Range: etherCON
Note: The cable connector carrier does not include an RJ45 plug, requiring separate purchase for complete assembly.
- Non pre-assembled RJ45 cable installations
- Harsh and demanding environments
- Commercial Ethernet applications
- Protecting fragile RJ45 connectors
- Shell Material: Black Chromium
- Cable Diameter Range: 3.5 - 8mm
- Modular Connector Type: RJ45 Plug
- Port Configuration: 1 x 1 (Port)
- No. of Positions / Loaded Contacts (per Port): 8P8C
- Connector Mounting: Cable Mount
- Connector Orientation: Straight
- Shielding: Shielded
- Magnetics: Without Magnetics
- LEDs: Without LED
- Light Pipes: Without Light Pipe
- Product Range: etherCON
