PRO ELEC 12-Pole Panel Mount Plug, Threaded, IP68, 400V AC, 5A
High-performance PRO ELEC 12-pole panel mount plug with IP68 rating, 400V AC, 5A, gold-plated brass contacts.
The PRO ELEC 12-Pole Panel Mount Plug is a high-performance circular threaded connector designed for robust applications requiring reliable electrical connections. Featuring an IP68 rating, it provides excellent protection against dust and water ingress, making it suitable for harsh environments.
Constructed with a durable nylon (polyamide) body and brass contacts plated with gold, this connector ensures long-lasting performance with low contact resistance. The threaded coupling design offers secure mating, capable of withstanding over 500 mating cycles without degradation.
Applications
This connector is ideal for industrial, automotive, and outdoor applications where secure and weatherproof connections are essential. Its wide temperature range (-25°C to +85°C) allows for use in extreme conditions, ensuring reliability in both cold and hot climates.
Specifications
- Cable Diameter: 7 - 12 mm
- IP Rating: IP68
- Rated Voltage: 400V AC
- Rated Current: 5A
- Temperature Range: -25°C to +85°C
- Dimensions (LxØ): 29 x 27 mm
- Product Range: SP211 Series
- Shell Style: Panel Mount Plug
- No. of Contacts: 12
- Contact Type: Solder Socket
- Coupling Style: Threaded
- Body Material: Nylon (Polyamide)
- Contact Material: Brass
- Contact Plating: Gold
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Industrial applications
- Automotive applications
- Outdoor applications
- Harsh environments
- Cable Diameter: 7 - 12mm
- IP Rating: IP68
- Threaded Coupling
- Mating Cycle: >500
- Rated Voltage: 400V AC
- Rated Current: 5A
- Temperature Range: -25°C to +85°C
- Dimension (LxØ): 29x27mm
- Product Range: SP211 Series
- Circular Connector Shell Style: Panel Mount Plug
- No. of Contacts: 12
- Circular Contact Type: Solder Socket
- Coupling Style: Threaded
- Connector Body Material: Nylon (Polyamide)
- Contact Material: Brass
- Contact Plating: Gold
- Weight: 20g
