PRO ELEC 6A Single Pole RCBO, C Curve, 30mA
PRO ELEC 6A RCBO with 30mA protection, C curve, 17.6mm wide. Ideal for residential and light commercial circuits.
The PRO ELEC 6A Single Pole RCBO combines circuit protection with earth leakage detection in a compact, 17.6mm module width. This residual current circuit breaker with overload (RCBO) ensures your electrical installations are safeguarded against overcurrents and earth faults, providing reliable protection for both people and equipment. With a breaking capacity of 6kA, it meets IEC61009 and EN61009 standards, ensuring compliance with rigorous safety regulations.
Designed for a voltage rating of 230V and a current rating of 6A, this single-pole RCBO is suitable for residential and light commercial applications. The C curve tripping characteristic makes it ideal for circuits with moderate inrush currents, such as lighting and general power circuits.
Key Features
- Breaking Capacity: 6kA
- Cable Compatibility: Up to 25mm²
- Width: 17.6mm per module (space-saving design)
- Standards: IEC61009, EN61009
- Voltage Rating: 230V AC
- Current Rating: 6A
- Poles: 1 (Single Pole)
- Trip Sensitivity: 30mA (ensures protection against electric shock)
Ideal for retrofitting into existing consumer units or new installations, the PRO ELEC 6A Single Pole RCBO offers enhanced safety, durability, and ease of installation.
Technical Specifications
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Residential consumer units
- Light commercial installations
- Electrical circuits with moderate inrush currents
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Breaking Capacity: 6kA
- Cable Compatibility: Up to 25mm²
- Width: 17.6mm per module
- Standards: IEC61009, EN61009
- Voltage Rating: 230V AC
- Current Rating: 6A
- No. of Poles: 1 (Single Pole)
Always follow local regulations and product guidance.
