TE Connectivity AMPMODU Mod II 2.54mm 3-Way Header
TE Connectivity AMPMODU Mod II 3-way, 2.54mm pitch pin header for reliable board-to-board connections.
The TE Connectivity AMPMODU Mod II Breakaway Pin Header delivers a versatile and reliable connection solution for various electronic applications. These headers feature a breakaway design, allowing customisation to any required size, ensuring maximum flexibility. Available in both straight and right-angle configurations, they are compatible with a range of mating receptacles, offering secure connections through different pin lengths and plating options.
Key Features:
- Current Rating: 3A max per contact
- Pitch Size: 2.54mm for precise alignment
- Operating Temperature Range: -55°C to +105°C, suitable for demanding industrial environments
- Contact Resistance: 20mΩ for efficient conductivity
- Insulation Resistance: 1000MΩ for dependable insulation
- Plating Options: Tin and gold-plated contacts for enhanced durability
- Interface Posts: 0.63mm posts ensure reliable mating with receptacles
- Termination Type: Through-hole straight for easy PCB mounting
- Contact Material: Phosphor bronze for superior conductivity and strength
Applications: Ideal for industrial uses and board-to-board connector systems, this header ensures a secure and efficient connection in various electronic setups.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
Technical Specifications
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Industrial connector systems
- Board-to-board PCB connections
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Current Rating: 3A max per contact
- Pitch Size: 2.54mm
- Operating Temperature Range: -55°C to +105°C
- Contact Resistance: 20mΩ
- Insulation Resistance: 1000MΩ
- Contact Plating: Gold/Tin-plated options
- Post Diameter: 0.63mm
- Termination Type: Through Hole Straight
- Connector System: Board-to-Board
- No. of Rows: 1
- No. of Contacts: 3
- Connector Shroud: Unshrouded
- Contact Material: Phosphor Bronze
- Product Range: AMPMODU Mod II
