BOURNS SMD Quick Blow Fuse, 2410, 1A, 125V AC

The BOURNS SinglFuse™ SF-2410FP100T-2 is a fast-acting, precision surface-mount fuse designed for reliable overcurrent protection in modern, compact electronic circuits. Featuring a robust ceramic tube construction and a standard EIA 2410 (6125 metric) footprint, it offers exceptional durability and stability while minimising board space. This component is ideal for automated assembly processes, supporting efficient, high-volume production.

Engineered for accuracy, this fuse provides precise circuit protection with a rated current of 1A and a typical resistance of 0.158Ω. It is rated for 125V AC operation and boasts high interrupting ratings of 50A at 125V AC/DC and 300A at 32V DC, ensuring it can safely clear significant fault currents. Its fast-acting characteristic is confirmed by a typical I²t value of 0.4143 A²s and will open within 5 seconds at 200% of its rated current.

Key Features & Benefits

• Fast-Acting Precision: Delivers accurate and reliable overcurrent protection for sensitive electronic components.
• Compact Footprint: The EIA 2410 (6125 metric) SMD package is perfect for space-constrained PCB designs.
• Robust Construction: Ceramic tube design ensures excellent thermal and mechanical durability.
• Automation Ready: Surface-mount packaging is tailored for streamlined, automated assembly lines.
• Broad Compliance: Meets UL 248-14 standards and is RoHS compliant and halogen-free, supporting environmental safety initiatives.
• Wide Operating Range: Functions reliably across an extensive temperature range from -55°C to +125°C.
• Reflow Friendly: With a Moisture Sensitivity Level (MSL) of 1, it is ideally suited for standard reflow soldering processes.

This fuse is a critical safety component for power supplies, consumer electronics, industrial controls, and telecommunications equipment, offering designers a dependable and space-effiic
