CLIFF 8-Pin Right Angle PCB DIN Socket Connector with EMI/RFI Screen
Robust 8-pin DIN socket connector with EMI/RFI screen. Right-angle PCB mount, tin-plated contacts, 4A rating. Ideal for audio/MIDI applications.
The CLIFF 8-Pin Right Angle PCB DIN Socket Connector is a robust, purpose-built component designed for consumer and professional audio equipment, including MIDI applications. Its right-angle PCB mounting design allows for space-saving installations, making it ideal for compact electronic assemblies.
Key Features
- Built-in EMI/RFI screen ensures superior signal integrity by reducing electromagnetic and radio-frequency interference.
- DIN 41524 standard compliance guarantees compatibility with industry specifications for reliable performance.
- Wave soldering compatible, facilitating seamless integration into production processes.
- Rugged construction utilises high-quality PBT (Polybutylene Terephthalate) for the connector body, ensuring durability and resistance to wear.
Technical Specifications
- Current Rating: 4A
- Voltage Rating: Up to 34V AC (low voltage)
- Contact Plating: Tin-plated for optimal conductivity and corrosion resistance
- Termination: Solder-contact for secure, long-lasting connections
- Mounting: Right-angle PCB mount for flexible installation
- Gender: Jack (socket)
This connector is a reliable choice for engineers and hobbyists alike, offering excellent performance in audio and electronic applications where signal clarity and mechanical stability are paramount.
- Consumer audio equipment
- Professional audio equipment
- MIDI devices
- Electronic assemblies requiring EMI/RFI protection
- Standard: DIN 41524
- EMI/RFI Screen: Yes
- Mounting Type: Right angle PCB mount
- Wave Soldering Compatible: Yes
- Current Rating: 4A
- Voltage Rating: 34V AC max (low voltage)
- Number of Contacts: 8
- Gender: Jack (socket)
- Termination: Solder
- Contact Plating: Tin
- Body Material: PBT (Polybutylene Terephthalate)
- Weight: 10g
