EUROPA TR2-D Thermal Overload Relay 1.6-2.5A

The EUROPA TR2-D Thermal Overload Relay provides reliable motor protection by safeguarding against overcurrents and phase failures. Designed for a setting range of 1.6-2.5A, this relay ensures precise overload adjustment to protect your electrical equipment from damage.

This thermal overload relay meets rigorous international standards, holding approvals for IEC 60947-1, IEC 60947-4-1, NFC 63-650, VDE 0660, and BS 4941. It features a tripping class of 10A and offers robust electrical insulation with an operating voltage of 690V/600V and frequency limits up to 400Hz.

Safety and Performance

Safety is paramount with integrated VDE 0106 protection against finger contact (IP2x). The relay also boasts impressive dielectric strength at 6kV (IEC 255-5) and impulse withstand voltage of 6kV (IEC 801-5). It exhibits high sensitivity to phase failure, with the tripping current activating 25% above In, and a precise tripping threshold of 1.14 0.06In.

Compact in design, the relay measures just 43 mm in height, 33 mm in width, and 15 mm in depth, weighing only 181 grams. This makes it highly suitable for installations where panel space is at a premium.
