HIROSE Mezzanine Connector Socket, 0.4mm, 2 Rows, 60 Contacts, SMD

The HIROSE Mezzanine Connector Socket is a high-density board-to-board connector specifically engineered for stacked PCB designs. Featuring an ultra-fine 0.4mm pitch, this socket allows for compact and efficient connections, making it an ideal choice for sophisticated electronic applications where PCB real estate is at a premium. With its 2-row configuration and 60 contacts, it provides a robust and reliable interface for signal transmission between parallel printed circuit boards.

Designed for surface mount device (SMD) installation, this mezzanine connector socket ensures a secure and stable attachment to the board during the soldering process. The contacts are manufactured from phosphor bronze, a material well-regarded for its excellent electrical conductivity, spring properties, and overall durability, ensuring long-lasting performance and consistent connectivity even in demanding operating environments.

Key Features and Specifications

• Pitch: 0.4mm
• Configuration: 2 rows
• Number of Contacts: 60
• Mounting Type: SMD (Surface Mount Device)
• Contact Material: Phosphor Bronze
• Dimensions: 43mm (Height) x 33mm (Width) x 15mm (Depth)

Whether you are developing complex telecommunications equipment, advanced computing systems, or compact consumer electronics, this mezzanine connector socket delivers the high-density interconnection required for modern stacked PCB architectures. Its precise engineering guarantees optimal alignment and mating, facilitating streamlined assembly processes.
