HONGFA DIN Rail Relay Socket, 7A, 250V AC

The HONGFA DIN Rail Relay Socket is a high-performance interface component designed to safely mount and connect control relays within electrical panels and control systems. Engineered with robust insulation properties, it features a dielectric strength of 2000V AC and an insulation resistance of 1000MΩ, ensuring reliable operation and safety in demanding industrial environments. Its compact design allows for efficient use of space on standard DIN rails, the universal mounting system for electrical components.

A key safety feature is the integrated finger protection device, which helps prevent accidental contact with live terminals, enhancing user safety during installation and maintenance. The socket utilises a convenient plug-in terminal design for quick and secure relay connection, simplifying wiring and reducing installation time.

The terminal blocks are designed to accommodate a maximum wire size of 1x 4mm² or 2x 1.5mm² (equivalent to 1x 12AWG or 2x 16AWG), with an optimal wire strip length of 7mm for a proper connection. With a current rating of 7A at 250V AC, this socket is part of the reliable HONGFA 18FF Series, suitable for a wide range of control and automation applications where dependable relay operation is critical.

Specifications

• Dielectric Strength: 2000V AC
• Insulation Resistance: 1000MΩ
• Current Rating: 7A
• Voltage Rating: 250V AC
• Maximum Wire Size: 1 x 4mm² / 2 x 1.5mm² (1 x 12AWG / 2 x 16AWG)
• Recommended Wire Strip Length: 7mm
• Mounting Type: DIN Rail
• Terminal Type: Plug-in
• Product Series: 18FF Series
• Special Feature: Finger protection device

This relay socket provides a secure, safe, and organised solution for integrating relays into control cabinets, machine wiring, and automation systems.
