IQD Frequency Products Crystal Quartz 32.768kHz SMD

The IQD Frequency Products Crystal Quartz 32.768kHz SMD is a high-precision timing component designed for reliable frequency generation in a wide range of electronic devices. This surface-mount crystal from the CFPX-56 series offers a nominal frequency of 32.768kHz, ensuring stable and accurate performance for real-time clock applications and other timing-sensitive circuits.

With a frequency tolerance of ±20ppm and a frequency stability of ±0.035ppm, this crystal provides excellent long-term reliability and minimal drift, making it suitable for applications where precise timing is essential. The load capacitance of 12.5pF ensures compatibility with typical oscillator circuits, while the compact 2mm x 6mm package and 2-pin SMD mounting allow for efficient use of PCB space.

This crystal operates within a temperature range of -10°C to +60°C, making it suitable for indoor and climate-controlled environments. Whether used in microcontrollers, RTC modules, or communication devices, this crystal delivers dependable frequency control in a small, surface-mount form factor.

Key Specifications:

• Frequency: 32.768kHz
• Frequency Tolerance: ±20ppm
• Frequency Stability: ±0.035ppm
• Load Capacitance: 12.5pF
• Package: 2mm x 6mm SMD
• Number of Pins: 2
• Operating Temperature: -10°C to +60°C
