JST Right Angle SMT Pin Header, 1mm Pitch, 4 Contacts

The JST Right Angle SMT Pin Header is a precision-engineered, surface-mount connector designed for compact electronic assemblies where space is at a premium. Featuring a 1mm fine pitch and a right-angle orientation, this header allows cables to be routed parallel to the PCB, significantly reducing the overall profile and enabling sleek, low-profile designs.

Constructed as a single-row, 4-contact connector, it provides a reliable wire-to-board interface. The surface-mount (SMT) SH type termination ensures a secure and stable connection directly to the circuit board, suitable for automated assembly processes. This design is ideal for applications demanding high-density interconnections without sacrificing reliability.

Its compact form factor, combined with the right-angle configuration, makes it an excellent choice for internal cabling in consumer electronics, telecommunications hardware, and compact industrial control systems. The fine pitch supports the trend towards miniaturisation in modern electronics.

Key Specifications

• Pitch: 1mm fine pitch
• Orientation: Right-angle
• Mounting Type: Surface-mount (SMT)
• Configuration: Single row, 4 contacts
• Interface Type: Wire-to-board
• Connector Series: SH type
• Dimensions (LxWxH): 43mm x 33mm x 15mm

This JST component represents a high-quality solution for efficient and space-saving electrical connections, ensuring consistent performance in demanding environments.
