KEMET T495 Tantalum Capacitor 22µF 35V ±10% 2917 (7343 Metric)

The KEMET T495D226K035ATE250 is a high-performance, low equivalent series resistance (ESR) tantalum surface mount capacitor from the T495 series. Designed for demanding electronic applications, this MnO2 capacitor is engineered to deliver high surge current and high ripple current capability, ensuring reliable operation in power-intensive circuits.

Built on proven industrial-grade tantalum chip technology, it offers several key benefits including low ESR, excellent capacitance stability, and improved resistance to high in-rush currents. These performance advantages are achieved through proprietary design, materials, and process parameters, combined with high-stress, low-impedance electrical conditioning performed prior to screening.

This capacitor provides a capacitance of 22µF with a ±10% tolerance, a 35V DC voltage rating, and is housed in a D case size (2917 / 7343 metric package). It features a 100% matte tin (Sn) plated termination finish and operates across a temperature range from -55°C to 125°C. Each unit undergoes 100% surge current testing and steady-state accelerated aging to ensure high reliability.

Typical applications include decoupling and filtering in automotive end applications, such as DC/DC converters, portable electronics, telecommunications equipment, and control units that require high ripple current capability.

Specifications

• Capacitance: 22µF
• Voltage Rating (DC): 35V
• Capacitor Case / Package: 2917 7343 Metric
• Capacitance Tolerance: ±10%
• ESR: 0.25Ω
• Manufacturer Size Code: D
• Ripple Current: 775mA
• Product Range: T495 Series
• Operating Temperature Min: -55°C
• Operating Temperature Max: 125°C
• Termination Finish: 100% Matte Tin (Sn)
• Compliance: Meets or exceeds EIA standard 535BAAC
• Epoxy: UL94 V-0 compliant
• Reliability: 100% surge current &
