MEAN WELL RSD-60H-12 Isolated DC/DC Converter, 12V, 5A, 60W

The MEAN WELL RSD-60H-12 is a robust 60W enclosed-type DC/DC converter from the RSD-60 series, designed specifically for demanding railway and industrial applications. With a wide 4:1 input range of 40 to 160VDC continuous, this converter delivers a fixed 12V output at 5A (60W) with a typical efficiency of 92.5%. Its ultra-compact 1U low profile (25mm height) and semi-potted interior make it ideal for space-constrained installations.

Featuring supreme EMC characteristics and 4000VDC reinforced I/O isolation, the RSD-60H-12 ensures reliable operation in harsh environments with high vibration, high dust, and extreme temperatures. The converter is cooled by free air convection and requires no minimum load, simplifying system design. Built-in protections include short circuit, overload, over voltage, and input reverse polarity, with a constant current limiting circuit for additional safety. A LED indicator confirms power-on status.

This converter is approved to IEC/UL/AS/NZS 62368-1 and EAC TP TC 004, with design reference to BS EN/EN62368-1. Its working temperature range is from -40 to +55°C without derating, making it suitable for railway, tram, bus, telecom, and industrial control systems.
