Mean Well Single Output PFC Power Supply 24V 42A 1008W

The Mean Well Single Output Power Supply is an enclosed AC/DC unit delivering up to 1008W of output power, designed for a wide variety of industrial applications. Operating on a universal AC input of 90 to 264V AC, this robust power supply provides a rated output voltage of 24V DC at 42A, meeting the demands of all kinds of industrial equipment.

Cooled by a built-in fan with intelligent speed control, the unit can reliably operate in ambient temperatures up to 70°C. It features built-in active Power Factor Correction (PFC) achieving a power factor of greater than 0.95, alongside a high efficiency rating of up to 94%.

Advanced Protection and Functions

This power supply is equipped with comprehensive protection features, including short circuit, overload, over-voltage, and over-temperature protection. It can also withstand a 300V AC surge input for up to five seconds. Additional built-in functions offer vast flexibility for industrial setups, including auxiliary power (standby 5V at 0.3A), remote sense, remote on/off control, and a DC OK signal. For higher power demands, the unit supports current sharing up to 4kW. Furthermore, it boasts low no-load power consumption of less than 0.75W.

Key Specifications

• Output Power: 1008W (1.008kW)
• Output Voltage: 24V DC
• Output Current: 42A
• Input Voltage: 90V AC to 264V AC
• Efficiency: Up to 94%
• Operating Temperature: Up to 70°C
• Protection: Short circuit, overload, over-voltage, over-temperature
• Cooling: Built-in fan with speed control
