MOLEX / BRAD Mini-Lock Pin Header, 2.5mm, 4 Contacts, Right Angle
MOLEX / BRAD Mini-Lock wire-to-board pin header. 2.5mm pitch, 4 contacts, single row, through hole right angle for PCB assemblies.
The MOLEX / BRAD Mini-Lock Pin Header is a compact wire-to-board connector designed for reliable PCB assemblies. Featuring a 2.5mm pitch, this single-row pin header accommodates 4 contacts, making it an ideal solution for space-constrained applications that require secure and efficient connections.
Engineered for through-hole right-angle mounting, this header facilitates edge routing on printed circuit boards, optimising layout and minimising vertical space usage. The right-angle configuration ensures a low-profile installation, which is crucial in modern, densely packed electronic devices where spatial efficiency is paramount.
Key Features
- Pitch: 2.5mm
- Contact Count: 4 contacts
- Row Configuration: Single row
- Mounting Style: Through hole right angle
- Design: Compact edge-routing header for PCB assemblies
Whether you are developing new PCB layouts or replacing existing components, the Mini-Lock series offers dependable performance and a robust interface for wire-to-board integration. Its precise dimensions and durable build quality ensure consistent electrical connectivity in demanding environments.
