NEUTRIK 4-Pole Male XLR Plug, Black
Durable 4-pole male XLR plug with gold contacts, POM strain relief & rugged zinc shell. Ideal for professional audio & lighting applications.
The NEUTRIK NC4MXX-B is a high-quality 4-pole male XLR plug designed for rugged and reliable audio, lighting, and signal transmission applications. It features solder contact wiring for secure connectivity, making it ideal for professional installations.
This connector boasts an improved chuck-type polyacetal (POM) strain relief, enhancing cable pull-out resistance and ensuring durability. The ergonomic design ensures easy assembly, while the reinforced housing provides robust protection against damage. Additionally, the internal thread on the shell adds further safeguarding.
Key Features
- Polyurethane boot protects against bending stress for extended cable life.
- Coloured rings & boots allow easy identification and coding.
- Latch lock mechanism ensures secure connections.
- Zinc die-cast shell with black chromium plating for durability and corrosion resistance.
- Gold-plated brass contacts for optimal conductivity.
- UL, cUL, IEC 61076-2-103, IP40 certified.
Technical Specifications
- Materials: Polyamide (PA 6.6 30% GR) insert, brass contacts (CuZn39Pb3), zinc die-cast (ZnAl4Cu1) locking element
- Dielectric strength: 1.5KVDC
- Rated current: 10A per contact
- Max voltage: <50V
- Temp range: -30°C to +80°C
- Wire size: Up to 16AWG (1.5mm²)
- 1000+ mating cycles lifespan.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Professional audio equipment
- Stage lighting systems
- Broadcast & sound engineering
- Cable assemblies for live events
- Poles: 4
- Gender: Male
- Mounting: Cable mount
- Strain Relief: Polyacetal (POM)
- Shell: Zinc die-cast, black chromium plated
- Insert: Polyamide (PA 6.6 30% GR)
- Contact Material: Brass (CuZn39Pb3), gold-plated
- Locking: Zinc die-cast (ZnAl4Cu1)
- Certifications: UL, cUL, IEC 61076-2-103
- Protection Class: IP40
- Rated Current: 10A per contact
- Voltage Rating: <50V
- Temp Range: -30°C to +80°C
- Wire Size: 16AWG (1.5mm²)
- Weight: 30g
Always follow local regulations and product guidance.
