NEUTRIK NCJ9FI-H XLR & Jack Connector, Gold Contacts, PCB Mount
NEUTRIK NCJ9FI-H hybrid XLR/jack connector with gold-plated contacts for high-quality audio connections. Ideal for studios & live sound.
The NEUTRIK NCJ9FI-H is a 3-pole female XLR receptacle with a 1/4-inch switching stereo jack, featuring gold-over-nickel-plated bronze contacts for superior signal integrity and durability. This Combo I series hybrid chassis connector combines an XLR receptacle and 1/4-inch jack into a single, space-saving horizontal PCB-mount unit, ideal for balanced or line inputs.
Key Features
- Robust Construction – Features a polyamide insert and steel Ck67 locking element for secure connections.
- Superior Signal Quality – Gold-over-nickel plating ensures low conductor capacitance, making it ideal for digital audio.
- Low Resistance – <10mΩ contact resistance (XLR) and <20mΩ overall contact resistance for high-fidelity audio transmission.
- High Insulation Resistance – >10GΩ insulation resistance prevents signal leakage.
- Versatile Applications – Suitable for audio equipment, mixing consoles, and professional sound systems.
Technical Specifications
- Current Rating: 7.5A per contact
- Voltage Rating: <50V
- Operating Temperature Range: -30°C to +80°C
- Housing Material: Metal body
- Mounting Type: PCB mount
This NEUTRIK connector simplifies PCB design, reduces costs, and saves space by consolidating two connectors into one compact housing.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Professional audio equipment
- Mixing consoles
- Sound reinforcement systems
- Studio recording setups
- No. of Contacts: 3
- Gender: Socket
- Contact Plating: Gold over nickel-plated bronze
- Connector Mounting: PCB mount
- Connector Body Material: Metal body
- Locking Element: Steel Ck67
- Insulation Resistance: >10GΩ
- Current Rating: 7.5A per contact
- Voltage Rating: <50V
- Temperature Range: -30°C to +80°C
