PRO ELEC 32A Single Pole RCBO, C Curve, 30mA, 230V
Compact PRO ELEC 32A single-pole RCBO with 30mA protection. 6kA breaking capacity, C-curve trip, for 230V UK circuits.
The PRO ELEC 32A Single Pole RCBO combines residual current protection with overcurrent protection in a compact design, offering enhanced electrical safety for domestic and commercial applications. With a breaking capacity of 6kA, this device ensures reliable circuit protection under fault conditions, preventing potential electrical hazards.
Designed for wiring systems with cables up to 25mm², this RCBO is ideal for a wide range of installations. Its 17.6mm width per module allows for efficient use of space in consumer units, making it suitable for both new installations and retrofit projects.
This RCBO complies with IEC61009 and EN61009 standards, ensuring high-quality performance and safety. Rated for 230V AC operation, it is tailored for UK electrical systems, while its 32A current rating makes it suitable for protecting higher-load circuits such as kitchens or workshops.
The C curve tripping characteristic ensures optimal protection against moderate surge currents, making it ideal for circuits with equipment that may experience temporary inrush currents without nuisance tripping.
With its single-pole design, it provides earth leakage protection (30mA sensitivity) and overcurrent protection, safeguarding both people and property from electrical faults.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Domestic consumer units
- Commercial distribution boards
- Circuits with high inrush current (e.g., lighting, motors)
- Kitchen and workshop installations
- Breaking Capacity: 6kA
- Cable Compatibility: Up to 25mm²
- Width: 17.6mm per module
- Standards: IEC61009, EN61009
- Voltage Rating: 230V AC
- Current Rating: 32A
- Number of Poles: 1 Pole
- Sensitivity: 30mA
- Tripping Curve: C Curve
- Weight: 190g
Always follow local regulations and product guidance.
