Dual Row 1.27mm Pitch 10-Pin Male Header to DIP-10 Adaptor

The Proto-Advantage Dual Row 1.27mm Pitch 10-Pin Male Header to DIP-10 Adaptor provides a reliable solution for converting 10-pin male headers to a 10-DIP format. Designed for versatility, this adaptor comes fully pre-assembled with top and bottom headers already installed, saving valuable time during your project assembly.

The top side features a gold plated dual row surface mount vertical male header, whilst the bottom side utilises two gold plated single row surface mount vertical male headers. The DIP pin type consists of robust wire wrap pins, measuring 0.64mm square, ensuring secure and consistent connections for your wire wrap applications.

Built with quality in mind, the PCB construction uses FR-4 UL94V-0 material, providing excellent thermal stability. The adaptor is rated for an operating temperature range from -40°C to +130°C, with a maximum reflow temperature of +260°C. It meets the IPC-A-610 Class II assembly standard, guaranteeing professional-grade performance and reliability for your electronic builds.

Key Specifications

• Pitch Spacing: 1.27mm
• Conversion: 10-Pin Male to 10-DIP
• Top Side: Gold plated dual row surface mount vertical male header
• Bottom Side: Two gold plated single row surface mount vertical male headers
• DIP Pin Type: Wire wrap pins (0.64mm square)
• PCB Dimensions: 17.78mm x 12.7mm x 1.6mm (700mils x 500mils x 62.5mils)
• PCB Material: FR-4 UL94V-0
