PROTO ADVANTAGE TSSOP14 to DIP14 Adaptor, 0.65mm
Convert TSSOP14 SMD to DIP14 with PROTO ADVANTAGE's FR4 adaptor. Ni/Au plated, includes headers & spacers.
The PROTO ADVANTAGE TSSOP14 to DIP14 Adaptor is a high-quality PCB-based solution designed to bridge surface-mount (SMD) and through-hole (DIP) connections. Constructed from 1.5mm thick FR4 epoxy fibreglass, this adapter ensures durability and reliable signal transmission for your electronic projects. The board features a double-sided 35µm copper layer, with both sides plated with chemical nickel/gold (Ni/Au) for excellent conductivity and corrosion resistance. Additionally, solder stop masks protect the board from unintended solder bridges.
Key Features:
- Top side fits TSSOP14 surface-mount connector footprint
- Bottom side accommodates dual single-row surface-mount vertical headers
- Prevents soldering errors with solder stop masks
- Includes PCB, headers, and spacers for straightforward assembly
Applications: Ideal for prototyping, testing, or adapting SMD components for breadboard-friendly DIP layouts, simplifying circuit development without soldering fragile surface-mount parts directly.
Specifications:
- Material: FR4 epoxy fibreglass
- Copper Layer Thickness: 35µm
- Surface Finish: Ni/Au plating
- Hole Diameter: 1.0mm
- Board Thickness: 1.6mm
- Dimensions (W×H): 17.78mm × 17.78mm
- Included Components: PCB, pin headers (SMD), 2x spacers
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Prototyping TSSOP14 components
- Breadboard adaptation
- Surface-mount testing
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Material: FR4 epoxy fibreglass
- Construction: Double-sided 35µm copper
- Surface Finish: Ni/Au plating
- Board Thickness: 1.6mm
- Hole Diameter: 1.0mm
- Dimensions: 17.78mm × 17.78mm
- Included: PCB, SMD headers, spacers
- Weight: 10g
