REAN Tiny XLR 5-Way Socket, Gold-Plated Contacts, Metal Body

The REAN Tiny XLR 5-Way Socket is a high-quality audio connector featuring a die-cast zinc shell for durability and a gold-plated bronze contacts system ensuring optimal signal transmission. Its POM strain-relief and polyamide insert enhance the robustness and longevity of the connection.

Designed for easy assembly, this socket includes a millionfold proven chuck-type strain relief that accommodates cables up to 4mm in diameter, preventing cable strain and breakage. The shielded system offers high noise immunity and EMI protection, making it ideal for environments with potential signal interference.

A keyed insert and strain-relief mechanism prevent mispositioning and rotation of the insert/cable, ensuring a secure and stable connection every time. The intuitive and rugged locking mechanism provides additional security, guaranteeing a firm and reliable connection for your audio setup.

Specifications

• No. of Contacts: 5
• Gender: Socket
• Connector Mounting: Cable Mount
• Contact Plating: Gold Plated
• Connector Body Material: Metal (Die-Cast Zinc)
• Strain Relief Type: POM, Chuck-Type (Up to 4mm Cable Diameter)
• Contact Resistance: Less than 10mR
• Insulation Resistance: Greater than 1GR

Applications

• Audio equipment connections
• Professional sound systems
• Studio recording setups
• Live performance audio gear
