TE Connectivity DTMH Wedgelock for 6-Way Plug Connectors

The TE Connectivity DTMH Wedgelock is a wedgelock for DTM series 6-way plug connectors, measuring 33 mm high, 22 mm wide and 2 mm deep. It locks contacts firmly in place within the connector housing for compact vehicle harnesses.

Overview

Designed for compact vehicle harnesses, the DTMH wedgelock keeps each contact securely seated, helping to prevent unintended disconnection. Its compact design integrates with the connector housing, and it is made from high-quality engineering plastic in black. The vibration-proof design is intended to prevent loosening in high-vibration environments.

Key Benefits

• Locks contacts firmly within the connector housing to help secure the connection.
• Vibration-proof design to help prevent loosening in high-vibration environments.
• Specifically engineered for TE Connectivity DTM series 6-way plug connectors.
• Lightweight and compact, suited to space-constrained applications.

Applications

The DTMH wedgelock can be used in a range of vehicle applications, including automotive wiring systems. It is also suitable for other compact harnesses where a secure connection is required in tight spaces.

Technical Specifications

• Compatibility: TE Connectivity DTM series 6-way plug connectors
• Model: DTMH
• Material: High-quality engineering plastic
• Colour: Black
• Height: 33 mm
• Width: 22 mm
• Depth: 2 mm
• Weight: 18.144 grams

Installation is straightforward for technicians and manufacturers, and the TE Connectivity DTMH Wedgelock is a suitable choice for securing contacts in DTM series 6-way plug connectors within compact automotive and harness designs.
