WINSTAR 8x32 Character LCD Display Module, White STN Negative, Blue

The WINSTAR 8x32 Character LCD Display Module is a high-quality monochrome display designed for clear information presentation. It features an 8 x 32 character format, providing a compact yet highly readable interface for a wide range of applications, from industrial instrumentation to point-of-sale terminals.

This module employs an STN (Super-Twisted Nematic) negative type LCD with a blue transmissive colour scheme, resulting in a crisp white on blue display appearance. The screen offers excellent contrast and readability with a defined character size of 2.96 x 5.56 mm. It includes a bright white LED backlight, ensuring clear visibility in various lighting conditions, and is optimised for a 6 O'clock viewing direction.

Key Features & Applications

• High-Resolution Text Display: With a dot pitch of 0.60 x 0.70 mm, it delivers sharp character definition for alphanumeric data.
• Versatile Interface: Controlled by the ST7066U IC, it supports standard English and Japanese fonts, making it suitable for international products.
• Compact Design: The module's slim profile, with dimensions of 58 x 32 x 13.2 mm, allows for integration into space-constrained designs.
• Robust Performance: It operates on a 3.3V logic supply and functions reliably across a broad temperature range from -20°C to +70°C, suitable for demanding environments.

This display is presented in a landscape orientation and is ideal for use in control panels, medical devices, test equipment, and any embedded system requiring a dependable character-based readout.
