Amphenol 9-Pin D-Sub Plug, Screw Terminals, Gold-Plated Brass Contacts
High-quality Amphenol 9-pin D-Sub plug with screw terminals, gold-plated brass contacts, and tin-plated steel shell.
The Amphenol L717DE09PST is a high-quality 9-way standard male D-Sub connector designed for reliable and secure electrical connections in demanding applications. Featuring gold-plated machined brass contacts, this connector ensures excellent conductivity and resistance to corrosion.
The D-ST series connector includes a tin-plated steel shell for durability and a UL94V-0 glass-filled thermoplastic insulator for superior electrical insulation and flame resistance. The screw termination design makes this connector particularly suitable for field applications where secure and stable connections are essential.
Key Features:
- Current Rating: 7.5A
- Voltage Rating: 300V AC at 50Hz
- Dielectric Withstanding Voltage: 1000V AC at 50Hz for one minute
- Insulation Resistance: ≥5000MΩ at 500V DC
- Contact Resistance: <5mΩ
Applications: This connector is widely used in automation & process control, HVAC systems, lighting, motor drive & control, and industrial applications, providing dependable performance in critical environments.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Automation & Process Control
- HVAC Systems
- Lighting Applications
- Motor Drive & Control
- D Sub Connector Type: Standard
- Gender: Plug
- No. of Contacts: 9
- Contact Termination Type: Screw
- D Sub Shell Size: DE
- Material: Tin-plated steel shell
- Insulation Material: UL94V-0 glass-filled thermoplastic
- Contact Plating: Gold-plated brass
- Current Rating: 7.5A
- Voltage Rating: 300V AC at 50Hz
- Dielectric Withstanding Voltage: 1000V AC at 50Hz for one minute
- Insulation Resistance: ≥5000MΩ at 500V DC
- Contact Resistance: <5mΩ
- Weight: 10g
Always follow local regulations and product guidance.
