CAMDENBOSS 3.81mm Pluggable Rising Clamp Terminal Block, 4-Pole, 8A
High-quality 3.81mm pluggable terminal block, 4-pole, 8A, ideal for secure wire connections in industrial applications.
The CAMDENBOSS 3.81mm Pluggable Rising Clamp Terminal Block is a high-quality, professional connector designed for secure and reliable wire termination. Featuring a rising clamp mechanism, this terminal block ensures a strong and stable connection for both solid and stranded cables (1.0mm², 28AWG to 16AWG). With its vertical female plug style and guided pin alignment, installation is quick and hassle-free.
Key Features:
- Anti-solder wicking for clean and secure connections.
- Captive screws prevent loss during installation.
- High insulation resistance (500Mohm/500V) and withstands voltage of AC2000V/1min.
- Contact resistance of just 20mohm ensures efficient performance.
- Wide temperature range (-40°C to 105°C) for versatile applications.
Constructed from nickel-plated brass and featuring a tin-plated brass pin, this terminal block offers superior durability and conductivity. The M2 steel, zinc-plated screws provide extra strength and corrosion resistance.
Technical Specifications:
- Pitch spacing: 3.81mm
- 4-position (4-way) connector
- Suitable for 28AWG to 16AWG wire
- Conductor area: 1mm²
- Rated current: 8A
- Rated voltage: 300V
Ideal for industrial and electrical applications, this CamBlock Plus series terminal block combines efficiency, longevity, and ease of use.
- Electrical wiring
- Panel installations
- Industrial control systems
- PCB connections
- Wire size: 1.0mm² (28AWG to 16AWG)
- Rising clamp mechanism
- Vertical female plug style
- Guided pin alignment
- Captive screws
- Insulation resistance: 500Mohm/500V
- Withstand voltage: AC2000V/1min
- Contact resistance: 20mohm
- Temperature range: -40°C to 105°C
- Material: Nickel-plated brass
- Pin material: Tin-plated brass
- Screw material: M2 steel, zinc-plated
- Length: 16mm
- Pitch spacing: 3.81mm
- No. of positions: 4-way
- Rated current: 8A
- Rated voltage: 300V
- Product range: CamBlock Plus
