CAMDENBOSS 5mm Low Profile Screw Terminal Block, 2-Pole, 16A
Compact 2-pole screw terminal block by CAMDENBOSS. Rated 16A/250V, ideal for secure electrical connections in tight spaces.
The CAMDENBOSS 5mm Low Profile Screw Terminal Block is designed for secure and efficient electrical connections with its 2-pole configuration and 16A rating. It features a compact, low-profile design with a pitch spacing of 5mm, making it ideal for space-constrained applications.
Key Features:
- Wire Size: Accommodates 1.5mm² conductors (22AWG to 14AWG), ensuring compatibility with a wide range of wiring applications.
- Test Probe Facility: Allows for easy testing and maintenance.
- Wire Protector Terminals: Protects wires from damage during installation and use.
- Guided Pin Alignment: Ensures precise and hassle-free alignment during connection.
- Durable Construction: Equipped with tin-plated brass pins and M2.5 zinc-plated steel screws for reliable conductivity and corrosion resistance.
Technical Specifications:
- Rating: UL=16A/250V, VDE=24A/250V
- Insulation Resistance: 500MΩ/500V
- Withstand Voltage: AC2000V/1min
- Contact Resistance: 20mΩ
- Operating Temperature: -40°C to 105°C
- Colour: Standard green finish
- Block Orientation: Through-hole vertical
Part of the CamBlock Plus series, this terminal block is perfect for industrial, commercial, and domestic electrical projects where reliable connectivity and compact design are essential.
- Electrical junction boxes
- Control panels
- PCB applications
- Industrial machinery wiring
- Pitch Spacing: 5mm
- No. of Positions: 2-pole
- Wire Size: 22AWG to 14AWG (1.5mm²)
- Wire Connection Method: Screw
- Rated Current: 16A
- Rated Voltage: 250V
- Insulation Resistance: 500MΩ/500V
- Withstand Voltage: AC2000V/1min
- Contact Resistance: 20mΩ
- Operational Temperature Range: -40°C to 105°C
- Terminal Material: Tin-plated brass
- Screw Specification: M2.5, zinc-plated steel
- Block Length: 10mm
- Colour: Green
- Block Orientation: Through-hole vertical
Always follow local regulations and product guidance.
