DUCATI Motor Run Film Capacitor 1 µF 450 V Wire Leaded

The DUCATI 4.16.15 series motor run capacitor is a high-quality metallised polypropylene film capacitor with wire leaded terminals, designed for reliable performance in industrial applications. Its construction uses an extremely thin metal coating applied by vacuum evaporation, ensuring efficient and stable operation.

The capacitor features a self-healing property that prevents short circuits, enhancing durability and safety. The case and cover are made from self-extinguishing plastic material, while the capacitive element is sealed with polyurethane resin, offering protection against leakage and environmental factors.

With low losses and non-inductive winding, this capacitor delivers excellent electrical performance. Its compact size and limited weight make it easy to integrate into various systems.

Key Specifications

• Capacitance: 1 µF
• Voltage (AC): 450 V
• Tolerance: ± 5%
• Dielectric: Metallised polypropylene (PP)
• Mounting: Stud mount – M8
• Terminals: Wire leaded
• dv/dt rating: 20 V/µs
• Operating temperature: -25°C to +70°C
• Dimensions: 43 mm x 33 mm x 15 mm
• Weight: 125 grams

This capacitor is ideal for industrial motor run applications, offering reliability and safety in demanding environments.
