Harwin DIL IC Socket, 16 Way, 7.62mm, 25 Pack

The Harwin DIL IC Socket offers a reliable interconnect solution for integrated circuits, designed with precision and durability in mind. Featuring four-leaf beryllium copper contacts, this socket ensures consistent and dependable electrical connectivity. The contacts are gold plated with a 0.25µ thickness, providing excellent conductivity and resistance to oxidation, whilst the tin-lead plated brass pins offer secure solderability to the PCB.

Built to withstand demanding environments, the socket boasts a glass-filled polyester body that is UL recognised, ensuring high mechanical strength and thermal stability. With a low body height of just 4.2mm, it is suitable for space-constrained applications. Furthermore, the design is auto-insertable, allowing for efficient and automated assembly processes which saves valuable time during manufacturing.

Key Features and Specifications

• 16-way DIP socket configuration
• Contact material: Beryllium copper with 0.25µ gold plating
• Pin material: Tin-lead plated brass
• Body material: Glass-filled polyester, UL recognised
• Pitch spacing: 2.54mm
• Row pitch: 7.62mm
• Body height: 4.2mm
• Auto insertable for streamlined PCB assembly

Supplied in a convenient tube of 25, these Harwin D28 range IC sockets are ideal for prototyping, production runs, and removable IC mounting.
