Membrane Tactile Switch, SPST-NO, 300gf, 48V DC, 125mA

This membrane tactile action switch is a round, momentary, single-pole single-throw (SPST-NO) device designed for reliable and responsive operation. The switch features silver-plated contacts for excellent conductivity and durability, a black face foil without legend for a clean, unmarked appearance, and a robust thermoplast PES socket/housing with a black thermoplast PBTP bezel. It is equipped with a tinned soldering aid for easy and secure installation.

The switch provides unique mechanical switches with tactile feedback, ensuring a clear and satisfying actuation with every press. Its compact design includes a small mounting depth, making it suitable for applications where space is limited. With an IP65 protection rating, it is protected against dust ingress and low-pressure water jets, suitable for demanding environments. The switch operates within an ambient temperature range of -25 to +60°C, ensuring reliable performance in a variety of conditions.

This momentary action switch is top-actuated with a round button actuator, requiring a 300gf actuating force for operation. It has a contact rating of 125mA at 48V DC and an insulation resistance of ≥10⁸Ω. The switch is part of the MCS18 Front Series and is designed for panel mounting. This product is non-illuminated, with dimensions of 18mm diameter. It weighs only 2 grams and measures 43mm in height, 33mm in width, and 15mm in depth.
