Molex KK 396 Break Away Header, Vertical, Square Pin, 12 Way, Tin Plated

The Molex KK 396 Break Away Header is a vertical, square-pin header designed for reliable wire-to-board connections. Its break-away construction allows you to snap the header to your required length, providing flexibility for various PCB configurations and helping to reduce inventory.

This 12-way header features a friction lock to secure the mating connector, ensuring a stable and dependable connection in applications where vibration or movement might otherwise cause disconnection. The tin (Sn) plated contacts offer good solderability and electrical performance, making this header suitable for a wide range of electronic assemblies.

Key Features:

• Break-away design – snap to length as needed
• Vertical orientation – ideal for straight board-to-wire connections
• Square pin contacts – provide secure and reliable mating
• Friction lock – helps prevent accidental unmating
• 12-way configuration – supports multiple connections in one header
• Tin plated – offers excellent solderability and electrical conductivity

Applications:

This header is commonly used in a variety of electronic devices, including consumer electronics, industrial controls, and automotive applications, where reliable wire-to-board connections are essential. Its ability to be trimmed to size makes it a versatile choice for design engineers.

Specifications:

• Brand: Molex / Brad
• Series: KK 396
• Type: Break-away header
• Orientation: Vertical
• Pin Type: Square
• Number of Ways: 12
• Locking Mechanism: Friction lock
• Plating: Tin (Sn)
• Weight: 4 g
• Height: 43 mm
• Width: 33 mm
• Depth: 15 mm

The Molex KK 396 Break Away Header is a practical and space-saving solution for your PCB to wire connections,.
