Multicomp Pro 3.81mm 4-Way PCB Terminal Block, Screw, 16-26AWG
4-way PCB terminal block with screw connections, 3.81mm pitch, for 16-26AWG wires. Ideal for industrial & electronic applications.
The Multicomp Pro MC000020 is a high-quality 4-way PCB terminal block with a 3.81mm pitch spacing, designed for reliable wire-to-board connections. Featuring tin-plated brass terminals and a green polyamide 66 insulating body, this terminal block ensures excellent conductivity and durability in a variety of industrial applications.
Its through-hole right-angle orientation allows for easy PCB mounting, while the screw connection type ensures a secure and stable wire hold for conductors ranging from 16AWG to 26AWG. With a strip wire length of 4 to 5mm, this terminal block provides flexibility in wiring configurations.
Key Specifications:
- Insulation Resistance: >2000MΩ
- Operating Temperature Range: -55°C to +105°C
- Rated Current: 10A
- Rated Voltage: 300V
Applications
- Industrial control systems
- Electronics prototyping
- Power distribution boards
- Please note:* Due to high market demand, lead times for this product may vary, and it is exempt from discounts.
- Material: Polyamide 66 (Insulating Body)
- Terminal Material: Tin-Plated Brass
- Pitch Spacing: 3.81mm
- No. of Positions: 4 Ways
- Wire Gauge Range: 16AWG to 26AWG
- Wire Connection Method: Screw
- Strip Wire Length: 4-5mm
- Insulation Resistance: >2000MΩ
- Operating Temperature: -55°C to +105°C
- Rated Current: 10A
- Rated Voltage: 300V
- Block Orientation: Through Hole Right Angle
- Weight: 900g
