MULTICOMP PRO 5.08mm 3-Way Right Angle Terminal Block Header
Industrial-grade 3-way right angle terminal block header with 16A/300V rating. Tin-plated brass contacts, polyamide 66 body.
The MULTICOMP PRO 5.08mm 3-Way Right Angle Terminal Block Header is a high-quality PCB mount solution designed for industrial applications. Featuring a green polyamide 66 insulating body and tin-plated brass solder pins, this terminal block header offers excellent electrical insulation and durability.
With an insulation resistance of >2000MR and an operating temperature range of -40 to +105°C, this component is built to withstand challenging environments. The through-hole right angle block orientation ensures easy installation and secure connectivity on your PCB.
Key Features:
- Material: Polyamide 66 insulating body
- Contact Material: Tin-plated brass solder pins
- Insulation Resistance: >2000MR
- Operating Temperature: -40 to +105°C
- Rated Current: 16A
- Rated Voltage: 300V
Please note: Due to high market demand, lead times for this product may be extended and delivery dates could fluctuate. This product is exempt from discounts.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Industrial applications
- Insulation Resistance: >2000MR
- Operating Temperature Range: -40 to +105°C
- Gender: Header
- Pitch Spacing: 5.08mm
- Number of Positions: 3 Ways
- Rated Current: 16A
- Rated Voltage: 300V
- Block Orientation: Through Hole Right Angle
- Weight: 900g
