NEUTRIK Speakon 8-Pole Female Connector Plug
Professional 8-pole Speakon plug with silver contacts, 30A rating & secure locking. Ideal for audio systems & loudspeakers.
The NEUTRIK NL8FC is an 8-pole female cable connector designed for high-current, inductive load environments, making it an ideal choice for professional audio applications. This Speakon industry-standard connector features silver-plated brass contacts for excellent conductivity and durability, ensuring reliable signal transmission even under demanding conditions.
The quick-locking mechanism and POM strain relief chuck (suitable for 8–20 mm diameter cables) provide secure cable retention and easy assembly. The PBTP insert and polyamide shell offer high-impact resistance, while the zinc die-cast locking element enhances structural integrity.
Key technical specifications include:
- UL94HB flammability rating
- Solderability compliant with IEC 68-2-20
- Contact resistance ≤3mΩ (after lifetime)
- Insulation resistance >1GΩ
- Continuous current rating of 30A RMS per contact
- Voltage rating of 250V
- Operating temperature range: -30°C to +80°C
Warning: This connector is not suitable for AC mains or power supply applications. Designed exclusively for professional audio systems, it provides a secure, touch-proof connection for loudspeakers and audio interfaces.
- Professional audio systems
- Loudspeaker connections
- High-current inductive load environments
- Stage and studio equipment
- No. of Contacts: 8
- Gender: Female (Plug)
- Contact Plating: Silver-plated brass
- Insert Material: PBTP
- Shell Material: Polyamide
- Locking Element: Zinc die-cast
- Cable Diameter Range: 8–20 mm
- Strain Relief: POM chuck type
- Flammability Rating: UL94HB
- Contact Resistance: ≤3mΩ
- Insulation Resistance: >1GΩ
- Current Rating: 30A RMS per contact
- Voltage Rating: 250V
- Temperature Range: -30°C to +80°C
- Weight: 80g
Always follow local regulations and product guidance.
