PRO ELEC SP211 Series 4-Pole IP68 Panel Mount Connector Plug
Durable PRO ELEC 4-pole IP68 connector with gold-plated brass contacts. Ideal for industrial & marine use.
The PRO ELEC SP211 Series 4-Pole IP68 Panel Mount Connector Plug is designed for robust and reliable performance in demanding environments. This high-quality connector features a threaded coupling mechanism, ensuring a secure and stable connection even under challenging conditions.
Constructed with a durable nylon (polyamide) body and brass contacts plated with gold, this connector offers excellent resistance to corrosion and wear, making it suitable for long-term use. With an IP68 rating, it is protected against dust ingress and prolonged submersion in water, making it ideal for outdoor, marine, or industrial applications.
Key Benefits
- High durability with mating cycles exceeding 500
- Maximum safety with a rated voltage of 500V AC and current of 30A
- Wide operating temperature range from -25°C to +85°C
- Compact dimensions (29mm x 27mm) for easy integration into panels
Specifications
- Material: Nylon (Polyamide) body with brass contacts
- Contact Plating: Gold
- Cable Diameter: 7 - 12mm
- Certification: IP68 rated for dust and water resistance
- Industrial machinery
- Marine equipment
- Outdoor electrical installations
- Panel mounting applications
- Cable Diameter: 7 - 12mm
- IP Rating: IP68
- Coupling Style: Threaded
- Mating Cycle: >500
- Rated Voltage: 500V AC
- Rated Current: 30A
- Temperature Range: -25°C to +85°C
- Dimensions (LxØ): 29x27mm
- Product Range: SP211 Series
- Connector Shell Style: Panel Mount Plug
- No. of Contacts: 4
- Contact Type: Solder Socket
- Connector Body Material: Nylon (Polyamide)
- Contact Material: Brass
- Contact Plating: Gold
