Schneider Electric 4 Pole Contactor, 690V AC

The Schneider Electric TeSys K Series 4 Pole Contactor is a reliable and compact solution designed for managing electrical circuits in industrial and commercial environments. Operating at a maximum voltage of 690V AC, this contactor is built to handle demanding applications with consistent performance.

Featuring a DPST-NO (Double Pole Single Throw Normally Open) and DPST-NC (Double Pole Single Throw Normally Closed) contact configuration, it provides versatile switching capabilities for various control circuits. The device supports a switching current of 20A AC1 and a resistive load current of 20A, ensuring robust operation for compatible loads. It is driven by a nominal coil voltage of 220V DC, offering precise and energy-efficient actuation.

Designed for flexible installation, this contactor can be mounted on a standard DIN rail or directly onto a panel, making it suitable for a wide variety of control cabinets and enclosures. With compact dimensions of 43 mm in height, 33 mm in width, and 15 mm in depth, and a lightweight design of just 231 grams, it easily integrates into space-constrained setups without compromising on functionality or accessibility.

Key Specifications

• Product Range: TeSys K Series
• Contact Configuration: DPST-NO, DPST-NC
• Operating Voltage: 690V AC
• Switching Current AC1: 20A
• Load Current Resistive: 20A
• Nominal Coil Voltage: 220V DC
• Mounting Options: DIN Rail, Panel
• Weight: 231 grams
• Dimensions: 43 mm x 33 mm x 15 mm (H x W x D)
